Voltage Drop Calculator

Calculate voltage drop for your landscape lighting installation. Ensure optimal performance by maintaining proper voltage at the end of your lighting runs.

Instructions for Use - HK Product Method (100% HK Lighting Systems Only)

  1. Run Length needs to be input from site plan or design. Wattage is calculated by product mix entered below.
  2. Input the quantity of each product below on each wire run to calculate voltage.
  3. On-site adjustment: The easiest way to modify end of line voltage when on site is to use the variable voltage tap on the transformer.
  4. Wire gauge can be modified in design process or on site. Increasing wire thickness (lower gauge) will reduce voltage drop.
  5. All wire needs to be direct burial copper landscape wire.
  6. Wire gauge and transformer tap have pull down menus. Run length should be input from design or onsite measurement.

Input Parameters

Accent Lights

ARTO-AL08
3.5W each
ARTO-AL11
7.5W each
ARTO-A16
9W each
ARTO-AL16
10W each

Path Lights

ARTO-PLLT
3.5W each
ARTO-PLMB
3.5W each
ARTO-PL11
7W each

Flood & Wall Wash

ARTO-FL08
3.5W each
ARTO-FL16
8W each
Total Wattage: 0W
Note: End run voltage values shown in green indicate optimal performance. Values in orange or red indicate caution - performance issues such as lower output and/or flickering may occur.

Calculated Results

Voltage Drop
1.33 V
End Run Voltage
10.67 V
System performance is optimal.
